S product name: NJU26040-16 a

S function name: 2 ch speaker system with digital signal processor

S profile

NJU26040-16 a is a 3 d surround sound, enhancement, equalizer, dynamic bass boost and automatic gain control (AGC)/limiter audio processing functions such as 24 bits digital signal processor. This product is best suited for docking type base speakers, TV, mini audio, radio and other audio equipment.

S performance characteristics

Low < software >

Low 3 d surround sound (eala NJRC (original); emphasizes the central position and a natural stereo sound field)

Low Stereo enhancement (eala Stereo Expander NJRC (original); even speakers interval is very close to, also can realize shock Stereo effect)

Low equalizer (5 band: double second-order filter (biquad filter). Band1, 2, 3: can choose HPF/parametric equalizer, Band4, 5: can choose HPF/parametric equalizer/bus/high)

When the master level (master volume)

Low dynamic bass boost (NJRC original) (2 ch independent of signal processing to fully ensure the height of the channel separating degree)

Low AGC/limiter

When the watchdog clock output

Low > < hardware

Low 24-bit digital signal processor

Low external clock frequency (maximum 38 MHZ)
